Product number: MUY-GW71VFD-A1
Mitsubishi Electric
| Product Group : | Hi-Wall - Mitsubishi Electric |
|---|---|
| Cooling Capacity : | 7.1 kW |
| EER : | 3.86 |
| Refrigerant : | R32 |
| Product Group : | Hi-Wall - Mitsubishi Electric |
|---|
| Indoor Units Connectable (Quantity) : | 1 | Single Split / Multi Split : | Single Split |
|---|
| Cooling Capacity : | 7.1 kW |
|---|
| Compressor Type : | Rotary |
|---|
| Power Supply : | 220-240/1/50 V/Ph/Hz | Recommended Fuse : | 20 A |
|---|
| EER : | 3.86 |
|---|
| Number Of Fans : | 1 |
|---|
| Depth : | 330 mm | Height : | 880 mm |
|---|---|---|---|
| Weight : | 48.5 kg | Width : | 840 mm |
| Max Height Difference : | 15 m | Max Piping Length : | 30 m |
|---|
| Refrigerant : | R32 | Refrigerant Pipe Size : | 1/4 - 1/2 in |
|---|---|---|---|
| Refrigerant precharged up to : | 15 m |
| Temperature Range Cooling : | -10 - 46 °C |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| Mits-Electric-MSY-GW-Series-Cooling-Only-2022-11-EN.pdf | Brochures | 4.42 MB |
