Product number: FP3349
Aspen Pumps
| Product Group : | Condensate Pumps |
|---|
The best-in-class Max Hi-Flow tank pump carries on the Aspen Pumps tradition of build quality & high performance. With the lowest dB(A) rating & best IP rating (IP24 splash proof) of any tank pump, the Max Hi-Flow is the quietest & safest pump in its class.
| Max Lift : | 5 m | Model Number : | FP3349 |
|---|---|---|---|
| Product Group : | Condensate Pumps | Type : | Condensate water pump |
| Flow Rate at 0 m : | 550 L/h | Max Discharge Head : | 5 m |
|---|---|---|---|
| Max Flow Rate : | 550 L/h | Max Water Temperature : | 40 °C |
| Tank Volume : | 1.7 L |
| Inlet Connection Size : | x4 21-27 mm | Outlet Connection Size : | 6 & 10 mm |
|---|
| Current : | 0.8 A | IP Class : | IP24 |
|---|---|---|---|
| Power Supply : | 230/1/50 V/Ph/Hz |
| Thermal Protection : | Yes |
|---|
| Commodity Code : | 84138100 | Country Of Origin : | DEU |
|---|
| Depth : | 285 mm | Height : | 134 mm |
|---|---|---|---|
| Width : | 144 mm |
| Water Flow Pressure : | 550 L/h |
|---|
| Pump Sound Level In App : | 44 dB(A) | Sound Pressure Level : | 44 dB(A) |
|---|
| Safety Switch : | 3 A NC |
|---|
| File name | Document Type | Extension | Size |
|---|---|---|---|
| user-manual-maxhiflow-en-ast-1974273.pdf | User Manual | 1.76 MB | |
| aspen-product-sheet-condensate-removal-pump-fp3349-en-ast-1856989.pdf | Data Book | 327.9 KB | |
| fp3349-aspen-max-hi-flow-condensate-pump-ast-332572.pdf | Technical Literature | 327.9 KB |
